1100 ATC Bearing Plate Kit (Direct Drive)

1100 ATC Bearing Plate Kit (Direct Drive Only)

For both 1100 3/4TTS and BT30

This Bearing plate kit you mount to the linear bearing blocks and pneumatic cylinder shaft to allow the ATC to slide into tool change position.

Features 6061 Aluminum bearing plate and Air cylinder shaft mount. Aluminum parts are powder coated light gray (Near Match to OEM)

Hardware included

• (2) M6 x 14mm Button head cap screws (for air shaft mount)
• (16) M4 x 12mm Cap screws (Bearing block screws)
• (2) M4 x 8mm Button head screws (for enclosure cover)

Product images for reference only actual part or system type may vary in shape, size, color, painted or not, hardware count and type.... just a disclaimer :)
